POCKET PULSE

[Art. 305]

Special Black & Gold Edition
INVERTER SINGLE PHASE COMPACT POWER SOURCE FOR MIG/MAG WELDING

  230V  50/60 Hz   +15%/ -20%

Benefits

User-friendly LCD Display

37 synergic curves including flux Cored welding

Short and Pulse functions

The lightest high-performance welding power source

 Our power sources have got International Certifications and Approvals



Demovideo display Cebora Pocket Pulse MIG 1820/M Synergic

Choose MIG/MAG Cebora

POCKET PULSE Special Black & Gold Edition

POCKET PULSE Special Black & Gold Edition is a synergic inverter single phase (230V 50/60 Hz +15% / -20%) for MIG/MAG welding with SHORT and PULSE function included.

  • 2-roller-wire feed unit (Ø 30 mm)
  • Equipped with ground lead ( 3 m - 16 mm2 )and clamp
  • 37 synergic curves (Solid Ø 0,6 / 0,8 / 0,9 / 1,0 mm;) Stainless steel (0,8 / 0,9 mm;) Aluminium (0,9 / 1,0 mm;) CuSi3% (0,8 / 0,9 mm;) flux- cored wire (Ø 0,9 mm). Cored wires can be welded, either with or without shielding gas, by simple polarity inversion.
  • The LCD Display allows the operator to read wire and gas type, current and thickness, voltage and wire speed
  • The power source is supplied with many adjustable functions which can be accessed from the panel, including:
    - Arc Length, 2/4 strokes, Spot Time, Pause Time, Inductance, Burn Back, Soft Start etc.
    SHORT or PULSEprocess
    - Three importants specific functions dedicated to an optimal aluminum welding (3 levels, Automatic Hot Start, Automatic Crater Filler)
  • The power source can also be powered by motor-driven generators of appropriate power ( 6 KVA)

Art. 305 Technical Specifications

230 V 50/60 Hz
+15% / -20%

Alimentazione monofase
Single phase input

16 A

Fusibile ritardato
Fuse rating (slow blow)

5,5 kVA 20%
3,7 kVA 60%
2,7 kVA 100%

Potenza assorbita
Input power

20 ÷ 185 A

Corrente min.-max. ottenibile in saldatura
Min.-max. current that can be obtained in welding

185 A 20%
140 A 60%
110 A 100%

Fattore di servizio (10 min. 40° C)
Secondo norme IEC 60974-1
Duty Cycle (10 min.40°C)
According to IEC 60974-1

Electronic

Regolazione continua
Stepless regulation

0,6/0,8/0,9/1,0 Fe
0,9 Cored
0,8/0,9 Inox
0,9/1,0 Al
0,8/0,9 CuSi3%

Curve sinergiche in dotazione standard
Standard supplied synergic programs

Ø 200 mm/5 kg

Bobina filo trainabile max.
Max. wire spool size

IP23S

Grado di protezione
Protection class

13,5 kg

Peso
Weight

196x458x380 mm

Dimensioni (LxPxH)
Dimensions (WxLxH)

  • Light metal fabrication
  • Handcrafting
  • Body shop
  • Routine maintenance
  • Agricultural industry
