WIN TIG DC 220 M

[Art. 553]

INVERTER SINGLE PHASE COMPACT POWER SOURCE FOR DC TIG AND MMA WELDING. HIGH FREQUENCY IGNITION

icons8-electrical-35.png  115 V 230 V  50/60 Hz   +15%/-20%

Benefits

User-friendly LCD Display

Evo Lift Ignition for a even more precise arc ignition

TIG functions available

Funzioni APC e Pulse XP

Our power sources have got International Certifications and Approvals



Choose TIG Cebora

WIN TIG DC 220 M

WIN TIG DC 220 M is an inverter single phase power source for TIG and MMA/SMAW welding except for AWS6010 coated electrodes+S64+S56

  • User-friendly LCD Display
  •  EVO LIFT function allowsto place the electrode in the exact position avoiding the piece oxidation and the heat control
  • EVO START function in order to optimize edge junction
  • APC TIG (Active Power Control) welding process which guarantees a deeper penetration, a more stable arch, avoids the electrodes to get stuck to the piece, allows to adapt the arc to the welding conditions only with the torch movement
  •  intermittence Pause Time Welding function which makes welding clearer with a time regulation in a second cents range
  •  Pulse functionselectable up to 2,5 kHz
  • eXtra Pulse (XP) function: avery high frequence pulse that works on small thicknesses where the transferred heat must be minimal
  • Possibility to match a low pulse frequence to the  XP process in order to improve the penetration and the welding speed on small-medium thicknesses
  • JOB function which makes it possible to save up to 9 welding programs
  • Wiz function helping the operator to take quick decisions based on the desired welding process
  • The power source can also be powered by motor-driven generators of appropriate power (10 kVA)
  • Pre-arranged for a cooling unit

Art. 553 Technical Specifications

TIG

MMA

115 V
50/60 Hz
+15% / -20%

230 V
50/60 Hz
+15% / -20%

115 V
50/60 Hz
+15% / -20%
230 V
50/60 Hz
+15% / -20%

Alimentazione monofase
Single phase input

25 A

16 A

25 A 16 A

Fusibile ritardato
Fuse rating (slow blow)

3,8 kVA 40%
3,1 kVA 60%
2,2 kVA 100%

5,3 kVA 30%
3,2 kVA 60%
2,7 kVA 100%

3,6 kVA 35%
2,8 kVA 60%
2,3 kVA 100%

4,5 kVA 35%
3,8 kVA 60%
3,4 kVA 100%

Potenza assorbita
Input power

5 ÷ 160 A

5 ÷ 220 A

10 ÷ 110 A

10 ÷ 140 A

Campo di regolazione della corrente
Current adjustment range

160 A 40%
140 A 60%
110 A 100%

220 A 30%
160 A 60%
140 A 100%



110 A 35%
90 A 60%
75 A
100%

140 A 35%
125 A 60%
115 A 100%

Fattore di servizio (10 min. 40° C)
Secondo norme IEC 60974-1
Duty Cycle (10 min.40°C)
According to IEC 60974-1

IP23S

Grado di protezione
Protection class

16 kg

Peso
Weight

207x500x411 mm

Dimensioni (LxPxH)
Dimensions (WxLxH)

  • Light metal fabrication
  • Handcrafting
  • Food industry
  • Body shop
  • Industrial & Energy plant
  • Routine maintenance
  • Agricultural industry
  • Construction of tanks
  • Off-shore industry
